Fusible Disconnect Switches
Telergon M3 fusible disconnect switches combine load-break switching and circuit isolation with Class J fuse protection for industrial and commercial AC applications. The U.S. range covers 30A, 60A, 100A, and 200A at 600VAC, with 3-pole and 3-pole + switched-neutral configurations. Products are designed to UL 98, CSA C22.2 No. 4, and IEC 60947-3, with short-circuit ratings up to 200 kA when applied as specified.
Filter By:
Key Features
- 30A to 200A rated current
- 600VAC rated voltage
- Class J fuse configurations
- Up to 200 kA SCCR at 600V
- 3-pole and 3-pole + switched-neutral configurations
- Direct and through-the-door operating options
Â
- NEMA / UL Type 4X external handle options
Technical Overview
Fusible disconnect switches combine load-break switching and isolation with fuse-based overcurrent and short-circuit protection. The disconnect provides the switching and isolation function, while the installed Class J fuses provide circuit protection.Telergon’s M3 range is designed for applications requiring a compact, manually operated fusible disconnect with SCCR ratings up to 200 kA.
Applications
Fusible disconnect switches are widely used in:
Industrial control panels
Power distribution equipment
Machinery and motor circuits
HVAC and building systems
OEM equipment requiring fusible disconnect protection
Compliance & Standards
- UL 98
- CSA C22.2 No. 4
- IEC 60947-3
- UL Guide WHTY, File E363652
- NEMA / UL Type 4X external operator handles available
Why Choose Telergon?
- Proven performance in demanding industrial environments
- UL 98 Listed solutions for U.S. applications
- Local U.S. presence for faster support, stocking, and distribution
- Competitive alternative to ABB, Eaton, and Socomec solutions
- Backed by Gorlan Group’s global expertise in switching solutions
Looking for fusible disconnect switches for your next project?
Contact Telergon for technical support, pricing, and fast delivery across North America.
